Tensioning Hydraulic Cylinder

  • ※ Max. Working Pressure : 70Mpa

    ※ Cylinder capacity : 28-900T

    ※ Closed height : 447-790mm

    ※ Stroke : 200mm

Product Features
  • Tensioning hydraulic cylinder, according to prestressed tension construction process and the design of the integrated numerical control cylinder, accepts computer commands and feeds back real-time tensioning data.
  • Integrated displacement and force sensor control unit, independent high-precision force measurement unit, to achieve the accuracy control of force and displacement.
  • 70Mpa working pressure, to achieve lightest weight of cylinder with the same tensioning force, reduce labor intensity.
  • Standard safety valve, protects the cylinder from damage of overload and ensures safe and reliable use.
  • Double acting, hydraulic return; baked enamel finish for increased corrosion resistance.
  • Aluminum alloy handles, lifting eye and mounting base, convenient for field applications and carrying.
  • 3/8 " '- 18NPT coupler and dust cap included on all models.
